CFD Analysis of a Heat Exchanger (SimScale, English)
Автор: simscale egitim
Загружено: 2023-01-05
Просмотров: 1492
Описание:
In this video, I simulated a simple heat exchanger design, using SimScales Conjugate Heat Transfer Analysis type.
The purpose of the study is to demonstrate the workflow. I did not pay attention on the accuracy of the analysis or the realistic conditions such as heat exchangers' flow rates.
This tutorial will show you
00:00 Intro
00:23 CAD preparation
02:07 Choose the analysis type
04:28 Adding the boundary conditions
08:12 Adding result control items
09:42 Convergence check
12:29 Post-processing
13:33 Create cutting plane with vectors
15:30 Crete particle traces
19:10 Create animation
