SOLIDWORKS ASSEMBLY TUTORIAL: How to design tailstock parts in Solidworks?

This is a tutorial video on how to design parts of a tailstock in Solidworks.
Other Assembly Tutorial Video:    • Designing Crane Hook Assembly in SOLIDWORKS

A tailstock, also known as a foot stock, is a device often used as part of an engineering lathe, wood-turning lathe, or used in conjunction with a rotary table on a milling machine. It is usually used to apply support to the longitudinal rotary axis of a workpiece being machined.
Just by using simple and basic commands like revolve, cut, extrude, we can create Solidworks models. this is a simple part for beginners who are new to Solidworks.
If you like this tutorial video and wish to get updates on the upcoming tutorial, subscribe to my channel and press the bell icon button for notifications.
---------------------------------------------------------------------------------------------------------------------------
CONTENTS OF THIS VIDEO
00:00 - Design sheet
00:20 - Part 1 - Body
23:31 - Part 2 – Feather key
24:40 - Part 3 – Barrel
28:07 - Part 4 - Spindle
34:22 - Part 5 – Spindle bearing
39:09 - Part 6 - Screw
41:35 - Part 7 – Key
42:22 - Part 8 – Hand wheel
49:29 - Part 9 – Stud
54:04 - Part 10 – Clamping lever
01:01:19 - Part 11 – Clamping plate
01:03:09 - Part 12 – Square bolt
01:07:03 - Part 13 – Dead center
---------------------------------------------------------------------------------------------------------------------------
