Voron 2.4 EBB36 v1.1 and U2C v1.1 Sensorless Install - Bonus Problems Included!
Автор: DeWZ
Загружено: 2022-12-04
Просмотров: 22468
Installing BigTreeTech's EEB36 v1.1 and U2C v1.1 on a Voron 2.4r2 with CW2 and Stealthburner. At the same time, converted to sensorless homing on the X and Y as well as using the Klicky probe for a Z Endstop.
I hit a road block after getting everything setup where my U2C board wasn't recognized by the PI and after trying to reflash it using STM32CubeProgrammer, it seemed to be bricked.
Using a mess of utilities, I was able to reflash it and move on with the install.
** This is how I was able to reflash my particular board, in my particular set of circumstances. It might not apply to or work for you, and it may do more harm than good. Full disclaimer. **
Proton CLI Tool:
https://docs.particle.io/archives/ins...
DFU-UTIL:
https://dfu-util.sourceforge.net/
Zadig USB:
https://zadig.akeo.ie/
Chapters:
0:00 Intro
2:05 The Real Truth
4:30 Things You May Need
5:27 Flashing the EBB36
10:23 Hardware Timelapse
12:23 Confirming Pinout
13:05 More Fastforward
13:40 U2C Trials and Tribulations
16:44 Unbricking the U2C
20:40 Side Quest - Static IP
22:40 Klipper Can Configuration
26:55 Sensorless Configuration
31:30 Sensorless Adjustments
37:40 Resetting the Bed (0,0)
44:15 Resetting Klicky Location
48:15 Klicky Probe as Z Endstop
52:00 Probe_Calibrate
