How to Model a Drum Kit With Parametric Modeling - BricsCAD
Автор: Bricsys®, part of Hexagon
Загружено: 2020-09-11
Просмотров: 3624
In this exercise, you will learn how to use parametric modeling to make a set of drums for a drumkit. You will do this by modeling one drum and adding parameters and constraints. All you need to do is change the values of these parameters to create the other drum sizes. You will finish by adding a design table.
00:00 Start
00:18 Add Parameters
00:46 Add a fix constraint
01:19 Add a radial constraint
01:37 Create a component
07:55 Edit an external component
08:30 Use parameters with an Array
09:24 Design tables
Parametric modeling is a great way of streamlining your CAD work. However, it's easy to feel daunted by tables, formulas, constraints and parameters. This is a practical, exercise, that anyone with a basic knowledge of CAD can follow. It will give you an idea of the basics of 3D parametric modeling in BricsCAD.
Download the project file: https://www.bricsys.com/static/files/...
Read the written instructions on the Bricsys Blog: https://www.bricsys.com/blog/make-a-d...
Download BricsCAD, free for 30-days: https://www.bricsys.com/bricscad-pro/...
