harman/kardon Onyx Studio 5 Onyx Studio 6 Speaker Battery replacement tutorial CS-HKE500SL
Автор: Cameron Sino
Загружено: 2020-10-07
Просмотров: 54331
Click "Show more" to see the entire description.
0:24 Pry off and remove the anti-slip rubber band
0:31 Loosen these screws and remove the bottom cover
0:50 Pry off and remove the front speaker grill cover (Take force)
1:15 Remove the nut and loosen these screws
2:02 Gently open the rear cover and unplug the speaker cord
2:16 Unplug and remove the original battery
2:19 Install and plug the Cameron Sino battery
2:31 Plug the speaker cord and install the rear cover
2:58 Tighten these screws and install the nut
3:32 Install the speaker front cover
3:45 Install the bottom cover and tighten these screws
4:12 Install the anti-slip rubber band
This is a speaker battery for harman/kardon Onyx Studio 5 or Onyx Studio 6.
Battery model: CS-HKE500SL
Capacity: 3500mAh / 12.95Wh
Voltage: 3.7V
Warranty: 12 Months
Difficulty: ★☆☆☆☆
Do you want more videos with different devices? Please comment and let us know which model you are looking for.
