Comacchio MC 15 Articulated Multipurpose Rig (2022) Exterior and Interior

2022 Comacchio MC 15 Articulated Multipurpose Rig seen from outside and inside. Engine is Cummins QSB 4.5 EU Stage IV, 119 kW. Total weight 16,500 kg. Types of rigs - Micropiloting, Anchoring, Jet Grounding, Landslide Reinforcement. Mast stroke 4,150 mm. Traction force 8 tons. Articulation - special, patented "Front The Wall" System, allowing tilting +/- 95° and perpendicular to the machine way - the change doesn't require to insert or remove hinges. Hydraulic - 1 axial-piston pump with changing debit 225/l min, 300 bar for the main functions (chains movement, Rig pipes movement, etc..), 2 gear pumps for the additional functions (oil cooling etc..). Rotation head - 2-speed type R1300, max torque 1300 daNm, max 350 rpm. Double bracket for diameters from 45 to 325 mm. Service traction winch with traction power 2,000 kg. Additional equipment - store for 10 probe pipes with max diameter 114 mm and max length 3,000 mm and grip. Remote control for all functions.

The machine was shown at ATEST EXPO 2022 - 30 March, 2 April, 2022, Sofia, Bulgaria.
