Diamond Mowers: Wheel Loader Boom Mower - In-Service Product Guide
Автор: Diamond Mowers
Загружено: 2020-02-28
Просмотров: 3069
Discover the components of your Wheel Loader Boom Mower and its maintenance requirements.
Watch a detailed overview of the parts in a Wheel Loader Boom Mower with a self-contained power unit.
The Wheel Loader Boom Mower with a self-contained power unit is one of two configurations Diamond offers. We will walk through the following parts of your Wheel Loader Boom Mower:
Attachment connectors
Power system, including the diesel fuel tank, and Tier 4 engine
Hydraulics system, including the tank, filters, and valves
Guard system and how to open it for maintenance
Direct drive spindle
Grease points to pay attention to
Trap door and rubber flap
Mower disc and blades
Cab controls
TIMESTAMPS
[0:07] Introduction
[0:20] Attachment hooks and cables
[0:48] Diesel fuel tank and Tier 4 engine
[1:10] Exhaust system
[1:20] Hydraulic tank
[2:10] High-pressure filter and ball valve
[3:13] Cooler
[3:42] Pump unloading valve, lift valve and accumulator
[4:27] Steel covers
[4:40] Actuator and anti-cavitation manifold
[5:30] Grease points
[5:45] Direct drive spindle and connections
[6:35] Rubber flap and trap door
[6:58] Disc and blades
[7:41] Inside the cab
[8:55] Contact us for assistance
Wheel Loader Boom Attachments: https://diamondmowers.com/products/wh...
Subscribe to Our Channel: / @diamondmowers
Follow Us:
Facebook: / demandbrilliance
Instagram: / diamond_mowers
Twitter: / diamond_mowers
LinkedIn: / diamond-mowers
*Specifications and design subject to change without notice.
