Testing a Frequency Generator Module (#57) - Also, now over 200 subscribers !
Автор: Martyn Davies
Загружено: 2017-11-19
Просмотров: 29003
Описание:
This $3.50 frequency generator module from icstation has a backlit LCD and covers frequencies up to 150kHz. I put it through its paces on the 'scope, and experiment with its serial interface.
Item was from icstation.com, but I've removed the link as Webutation reports some malware at that URL. Sorry for that.
STM8 microcontroller: http://www.st.com/en/microcontrollers...
HT1621 LCD driver:
http://pdf.datasheetcatalog.com/datas...
Edit: I get the serial interface working in part 3: • Frequency Generator Part 3 - Making the Se...
