Re, Convection Coefficient and Nusselt No. Calculations in ANSYS Fluent
Автор: Saud T. Al Jadir
Загружено: 2019-07-22
Просмотров: 51023
This tutorial was about fluid flow within a circular tube; you will learn in this video:
1- How to make a special mesh for the case considered.
2-How to set up ansys fluent for required calculations.
3- How to calculate Reynolds number, convection coefficient and Nusselt number.
- - - - - - - - - - - - - - - - - - - - - - -
The expressions appeared in the tutorial were listed below:
Re=(997 [kg/m^3]*0.05 [m]*areaAve(Velocity)@inlet )/0.000891 [kg/m/s]
h=areaAve(Surface Heat Transfer Coefficient)@fully_developed
Nu=(h *0.05 [m])/(0.607 [W/m/K])
- - - - - - - - - - - - - - - - - - - - - - -
Also; to download the geometry file, please click on the following link:
https://drive.google.com/file/d/1Q8Xv...
