Winch - Manual In-Out Switch Installation On Harbor Freight 12K Winch

In this video I am going to install a manual momentary switch on my Harbor Freight 12,000lb winch. This will be used as a backup switch to the remote or if I just want to used a manual switch from the toolbox. If testing contact with a multi-meter you will have to disconnect the wires from the remote switch going to the solenoid or the meter will read through the coil on the winch solenoid and give you continuity all the time when you press the in and out buttons on the remote. Black is the ground and there is no need to remove it to test.

I am not a professional. This video is for entertainment purposes only. I am not sponsored by any company mentioned in this video. I purchased all the products in this video with my own money. I did this install based on my own research and I recommend you research the parts and specs own your own for best results.


Links to parts used
12V Winch Switch with Mounting Bracket Winch Rocker Thumb Switch for ATV UTV Polaris Sportsman RZR Warn Badlands Arctic Cat Champion KFI Ramsey Master Lock 4 Wheeler Handle Bar Control Switch
https://www.amazon.com/dp/B08PRQP5KZ?...

ANCIRS 15pcs Semi-Insulated Piggyback Spade Connectors, Quick Disconnect Piggyback Spade Assortment Kit, Female/Male Cable Crimp Terminals, 22-10 AWG
https://www.amazon.com/ANCIRS-Semi-In...

#8-32 x 1/2" Truss Head Phillips Machine Screws, 304 Stainless Steel 18-8, UNC Full Machine Thread, Bright Finish, Quantity 50Pcs
https://www.amazon.com/KOSJETHAS-Phil...


Quantity 50Pcs 1/4-20 Nylon Insert Hex Lock Nuts, 18-8 Stainless Steel /SUS304/, Plain Finish, by Fullerkreg
https://www.amazon.com/Fullerkreg-Ins...

Flat Washer - 8# 304 Stainless Steel Metal Washers Flat for Screws and Bolts,7/16" Outside Diameter - 100PCS
https://www.amazon.com/Flat-Washer-St...

Conext Link RTV-38Y25 Vinyl Ring Terminal 25 Pack (3/8" Stud, Yellow 12-10 Gauge)
https://www.amazon.com/Conext-Link-RT...
