Cut Circles on a Bandsaw
Автор: Darbin Orvar
Загружено: 2015-07-21
Просмотров: 83790
Subscribe for weekly projects! In this video I show all the steps to building a circle cutting jig for a bandsaw.
Cut List and Metric Measurements
The distance from your blade to the miter track runner will vary with brand.
Wood: 1/2 " (12 mm) Baltic Birch Plywood
A) 1 @ 19 x 15 x 1/2" (483 x 381 x 12mm) - main board
B) 1 @ 10 x 15 x 1/2" (254 x 381 x 12mm) - top side 1
C) 1 @ 7 x 15 x 1/2" (178 x 381 x 12mm) - top side 2
D) 1 @ 2 x 15 x 1/2" (50 x 381 x 12mm) - main track
E) 1 @ 1 x 18 1/2 x 1/2" (25 x 470 x 12mm) - bottom miter t track
F) 1 @ 2 x 15 x 1/2" (50 x 381 x 12mm) - bottom back stop
G) 2 @ 2 x 2 x 1/2" (50 x 50 x 12mm) - knob
3/4" Screws - 20mm
1 1/4" Screws - 30mm
1 @ 1/4" dowel 6mm, cut to 20mm
1 @ 1/4 " pronged tee nut
1 @ 1 1/4" bolt
15" Seamstress measuring tape 381mm
