Low cycle fatigue test according to ASTM E606 at elevated temperature
Автор: ZwickRoellTV
Загружено: 2022-02-21
Просмотров: 9402
Materials that are subjected to extreme thermal and mechanical loads can only be designed within the range of their low cycle fatigue, i.e. up to a maximum of 10^5 load changes. Prime examples include turbine blades and discs used in aircraft engines and stationary turbines for power-generation.
The video shows the test of a threaded specimen on a servo hydraulic testing machine. The machine has an integrated power unit and does not require additional cooling. It is equipped with a short high temperature furnace and hydraulic high temperature grips for clamping. The software testXpert R will deliver all relevant results required by the ASTM E606.
00:07 - System overview
00:29 - Checking alignment
00:41 - Mounting specimen into grips
01:54 - Running test
02:21 - Data export
02:32 - Advantages and features
#LowCycleFatigueTest #ASTME606 #FatigueTesting
