Ansys Maxwell - Intro 3, 2D Analysis
Автор: Circuit Analysis
Загружено: 2023-07-27
Просмотров: 5049
2D Electromagnetic (EM) Finite Element Analysis (FEM) in Ansys Maxwell (previously Ansoft). This tutorial goes over how to simulate a 2D model in Maxwell. This includes setting up the material properties, setting up the excitation signals, creating circuit using the integrated SPICE simulator (Simplorer), defining and refining the mesh, setting up reports to view the results and error checking and troubleshooting. This follows 2 videos where a model was created in PEmag and simulated in 3D. This contains the following section:
0:00 Intro
0:19 PEmag
0:50 Maxwell
2:21 Materials
4:33 Sim Setup
5:40 Excitations
10:51 Simulation
11:51 Results
14:17 Model Depth
15:34 Refine Mesh
20:25 Extra Tips
22:38 Conclusion
