FreeCAD: Over Built Surface Technique With Trim Surface Tool | Basic Surfacing #4
Автор: MangoJelly Solutions for FreeCAD
Загружено: 2024-04-21
Просмотров: 8241
We will learn in FreeCAD how to create a over-built surface and use the trim tool to trim parts of the surface away with sketches. Overbuilt means that the surface initially exceeds the size of the original object, and then the excess is trimmed away using projected sketches. We will teach you how to use the Curves workbench to do this.
In our first example, we will examine the workflow of how to build a stylized chair. Form there we will move onto a more complex form where we combine two surfaces together.
#FreeCAD , #CAD , #3DPrinting
