Introduction to LTSPICE - OP-AMP Frequency Response and Slew Rate (Intermediate)
Автор: Electrical Engineering Topics
Загружено: 2020-09-17
Просмотров: 10604
Описание:
In this video I will show you how to build non-inverting amplifier using ADI OP27. Then we show the frequency limitations and slew rate applied to AC analysis and sine wave. We have also shown that the unity gain amplifier is stable with under damped response that leads to 20% overshoot.
