16" Shadow® Overflow by Synergy Reef®

The new Synergy Reef 16" Shadow® Overflow.

http://synergyreef.com/product/16-sha...

Specs:

Up to 2500 Gallons Per Hour Flow Rates!

Front Overflow Box
16" x 1.6" x 5.5" Injection Molded with durable Polycarbonate material
Removable Weir with VTeeth™ Technology ( Allows you to remove and clean the teeth of the weir)
Bulkheads are molded into the Front Overflow Box. No more separate bulkheads.
Fits aquarium thickness from 1/4" (15 mm) up to 3/4" (45mm) Glass or Acrylic tanks

Rear Box
16" x 3.75" x 7" Injection Molded Seamless Translucent Black ABS
3 x 1.5" ABS Slip fittings for easy plumbing
2 x U-Flow™ fittings that allow for compact plumbing
3 Pipe Full Siphon Overflow capability!
Removable Solid Black Polycarbonate lid that locks into place when closed (reduces noise, eliminates salt creep and light from entering the rear box)



Here are some of the key features of this overflow:

Ultra slim design with the internal overflow box only 1.6" in thickness!
Injection Molded with precision 3D CAD designed components.
Nearly Invisible when installed.
Removable weir with our new VTeeth™ for easy maintenance and cleaning. We have designed a simple slide fit that allow for a smooth action when removing the weir in tight spots under the trim on your tank. This means ZERO Clearance is needed to remove the weir when installed under a braced tank!
VTeeth™ or Velocity Teeth allow for a even surface skimming flow into the overflow. This maximizes the surface skimming capabilities of the overflow
Proprietary U-Flow™ plumbing components are included for easy plumbing. You only need 3 small pieces of 1.5" PVC Pipe.
Only overflow system on the market that can utilize 1.5" plumbing is this small rear box.
Rear box allows for various plumbing combinations, including the popular full siphon system (aka bean animal)
Will work on any non tempered glass and acrylic tanks from 1/4" (6 mm) to 3/4" (19 mm) Thick! Rimless and Plastic trimmed tanks all work!
Simple installation, installs in minutes.
Designing the overflow -

Being reef hobbyists ourselves, we spent years working on the design of this overflow. We tested hundreds of variations and options before we came to this design. Our fundamental goal was to create a low profile and quiet internal overflow box, while maintaining the flow rates desired by reef hobbyist. We wanted a overflow system that everyone would want to use. Designing the overflow with 3D software allows us to add features not possible when building it by hand out of flat acrylic. This overflow system was designed by Synergy Reef Systems in the USA!

Manufacturing the overflow -

Staying true to our company's "Made In The USA" motto, the Shadow™ is 100% Made In The USA! Every component of the overflow is molded right here in Tennessee. We use the highest quality US produced Polycarbonate and ABS in our molding process. Our quality is second to none! There are lots of imitation overflows out there, but ours is the highest quality available, period!
