112 - Changing the firmware for the transistor Tester kit

This video is about changing the firmware for the transistor tester kit which I built in part 1. This is definitely worth it because the new firmware by the two people maintaining this project offers so much more in test capabilities for this hardware.

Part 1 (building the kit):    • #108 Building and testing an eBay Transist...
Documentation and firmware can be found here: https://github.com/mikrocontroller-ne...
(this particular kit seems to be known as the: mega328_color_kit)

I am using a TL866II+ for burning the firmware and a program called Minipro by David Griffiths. The compilation and installation is shown here: in    • #111 Using a TL866II+ for ATmega328 progra...
and I am using David's instructions for compiling minipro to setup part of the programming environment on a fresh install of Linux Mint. See https://gitlab.com/DavidGriffith/mini... for the commands used.

I put up my configuration and firmware files for the two versions shown in the video 1.13K and 1.46M on my Github page
https://github.com/TheHWcave/Transist...

You can support the channel by becoming a patron. https://www.patreon.com/user?u=45604138
As a patron you get early access to all my videos as well as exclusive content.

00:00 Intro
00:39 preparations
03:49 OrigChina test
05:29 mega328_color_kit
06:22 makefile changes
08:17 my 1.13K version
08:56 about 1.46M
10:17 config.h
14:04 config_328.h
16:18 a bug
17:04 bug fix
17:55 my 1.46M
18:14 testing z-diodes
20:05 conclusion
