RCSchims Ultimate FPV-Antenna test 2019 (many omnis, patches and helicals accuratley tested!)

Please support with 👍 and 🔔 thanks ;-) it helps a lot!
USE the Jumpmarks in my VIDEO INDEX below! Find many links and infos further down! HERE is the EXCEL RESULTS sheet: http://bit.ly/2XI0PRq

Same test 2018:    • RCSchim's ULTIMATE FPV-Antenna test
Aaronia Spektran review (the DB measurement device):    • Aaronia Spectran HF6065 Review - very powe...
My test-setup:
I use 1mW on the transmitter, 5m distance to a VERY SENSITIVE receiver (Aaronia Spectran HF6065 -150dB!) and take enough samples from the -DB reading on the display to get an average.
The VTX is warmed up before the test - this way I can be sure it stays at the same output level for all antennas. This is not 100% accurate. On start I had 815uW and after 1h testing it showed 1029uW or 1mw - but this should not impact measurements too much!

!DISCLAIMER! - ORT sent me some antennas for review, you can buy them here: http://bit.ly/2OJ2hiG
Banggood sent the Foxeer Lolli3: http://bit.ly/2D60FtR
I DONT use affiliation links - I'm not a sales guy, here you get HONEST reviews and opinions.

►►►MORE Antenna links in the XLS Overview! https://goo.gl/ZsN6vs

●▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬●
VIDEO INDEX:
00:00 Intro
00:03:23 AOMWay SPW
00:03:42 Lollipops
00:04:20 Lollipop2
00:04:50 Lollipop Stubby
00:05:34 Lollipop3
00:05:59 SpeedyBee
00:06:55 ORT Pagoda
00:07:40 Foxeer Pagoda Long
00:08:07 ORT 6lobe SPW
00:09:02 ___Patches
00:09:48 IRC 8dbi Patch
00:10:25 MenaceRC PicoPatch
00:11:02 ORT Shield
00:11:54 ORT DualShield
00:14:17 Foxeer Echo
00:14:38 Foxeer Cat?
00:15:00 TFP
00:15:50 TFP Big
00:16:45 VAS Crosshair Extreme
00:17:59 ___Helicals
00:18:23 ORT Helix 3.5
00:20:14 CWL Helix 7.5 Turn
00:21:32 ORT Helix 6,5 Turn
00:22:50 ORT Helix 3 vs 7turn diff on more distance
00:24:40 Foxeer Cat thru Goggles
00:25:10 Handover the season, DJI HD Fpv...

●▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬●
