Trane RTHD series chiller Control boards and devices (LLIDS) connections explained (Part 1)
Автор: UATechnical Solutions
Загружено: 2023-08-13
Просмотров: 3212
Trane RTHD series chiller Control boards and devices (low level intelligent devises) connections and locations of the boards are explained in details (Part 1) part 2 will be coming soon, Following boards are explained,
Power supply Module
Compressor wye delta starter Starter Module (1A3)
Dual High Voltage Binary Input (1A4) high pressure switch
Dual Triac Output Module (1A5) Operates load / unload solenoids
Dual Triac Output Module (1A6) Operates Gas pump drain and fill solenoid valves
Dual High Voltage Binary Input 1A7 Monitor water flow switch and pump interlock
Dual Relay Output Module (1A8) Ice building status
Dual Relay Output Module (1A9) start chilled and cooling water pump
Quad Relay Output Module (1A10) Alarms and status relay output
