2GRFE MR2 SW20 Install Instructions Video #3

In this video I go over wiring the 2gr-fe engine into the 1993 MR2. It’s a bit of a long video because I go into a bit of detail as to why and how I am making my decisions. After seeing how long this video ended up being, I may make a more short and to the point video in the future. Please feel free to comment with suggestions if this is something you’d like to see.

Here are the diagrams used in the video:
Standalone 2gr-fe harness for rav4 ECU: https://FrankensteinMotorworks.com/2G...
2gr-fe harness for 1993 turbo chassis with rav4 ECU: https://FrankensteinMotorworks.com/2G...
Stock ECU jumper harness for 1993 turbo: https://FrankensteinMotorworks.com/2G...

Here are some of the relevant factory wiring diagrams:
“2-plug” rav4 wiring diagram: https://FrankensteinMotorworks.com/2G...
“5-plug” Avalon/highlander/sienna wiring diagram: https://FrankensteinMotorworks.com/2G...

You can buy the Frankenstein Motorworks parts here: https://frankensteinmotorworks.com/

And here are some of the tools I used that you may not already have. Note that the amazon links are affiliate links, I will make a bit of extra money if you buy through these links but it will not affect your purchase price:
Terminal extractors: https://amzn.to/2wzx38c
3-pin coolant sensor: https://amzn.to/2TMBEvo
3-pin pigtail: https://amzn.to/337Xv57
Heat gun: https://amzn.to/2PRBJgc (note the one i use is not available anymore, just get a 1000W or higher one otherwise you’ll be waiting forever. The 300W units are just too weak)
Ratcheting crimpers: https://amzn.to/2vNf0Lv
Dual wall heatshrink: https://amzn.to/2wx5lZM
Uninsulated butt crimp terminal 22-18ga: https://amzn.to/2Tuq5dx or cheaper on Waytek if you order multiple things and can spread the shipping: https://www.waytekwire.com/item/30270...
Uninsulated butt crimp terminal 16-14ga: https://www.waytekwire.com/item/31070...



If you have any further questions, please feel free to comment or e-mail: Marc@frankensteinmotorworks.com
