FP605 Installation and Startup

This eLearning Module covers the drive setup for Yaskawa's FP605 Industrial Fan and Pump drive:

What's in the box (0:48)
Quick and easy setup (2:00)
Step 1: Confirm specifications (4:03)
Step 2: Confirm environment (4:47)
Step 3: Use drilling template (5:24)
Step 4: Prepare wires (6:07)
S tep 5: Remove front cover, conduit brackets, and knockouts (7:17)
Step 6: Install wiring (7:47)
Step 7: Replace cover and keypad (8:47)
Step 8: Energize drive (9:03)
Step 9: Set motor FLA (9:48)
Step 10: Check motor rotation (11:24)

Additional Procedures
Step A Rotation Correction (12:55)
Step B, C, and D: Control Circuit (13:47)
Step E and F: Frequency Reference and Run Command (13:58)
Step H and I: Parameter Groups and Troubleshooting (15:32)
Review questions (15:44)

This eLM is also available on the Yaskawa America, Inc. - Drives & Motion Division learning management system, "Learn with Yaskawa". Keyword: eLM.FP605.01.drivestart
