Vantage Installation Series | Video 7 | Wiring
Автор: Avidyne
Загружено: 2025-11-14
Просмотров: 201
This comprehensive wiring guide covers multiple systems including Skywatch/Skytrax 200 harness buildup and installation. We'll show ST200 power connections through the Skywatch breaker and EGPWS, antenna connection to the existing transponder antenna, intercept wiring with existing Skywatch systems, and connections to IFDs and Vantage displays.
The AXP322 section covers complete harness buildup, power relocation from the existing transponder breaker, new antenna connections, and proper breaker relabeling using the provided Vantage kit labels.
Additional topics include Vantage 12 harness installation, IFD monitor audio and alert wiring to the AMX240 (including the three direct inputs for autopilot, IFD, and Skytrax), balancing resistor installation, DFC90 autopilot flap sense wiring, and Nav splitter relocation.
