How to verify and troubleshoot a no fuel pressure problem - Jeep

In this video I will walk you through some basic tests on verifying spark, injector pulse and fuel pressure. All you need is a digital multimeter and a small pocket screwdriver. I will be using the Power Probe IV but this is not a necessary tool to handle this problem. I chose this particular tool due to the long reach of the cables and the direct connections to the battery. This allowed me to not worry about finding a good ground underneath the rusty vehicle when i came time to verifying the fuel pump power and ground.

Engine Performance Diagnostics chapter 16

Symptoms
cranks but does not start

Fix
replace faulty fuel pump

Tests shown
how to test for spark
how to test for injector pulse with a Power Probe IV
how to test for fuel pressure without a gauge
how to test fuel pump power and ground

Tools used
Power Probe IV (a DMM may be used as a substitute)
pocket screwdriver

Playlist
