Building a Model Layout in the Garage - Part 33 - Control Panel Revisited

After watching another youtuber show off their control panel and having an issue with the button on mine, I decided to change the panel to using different buttons. The panel is a custom one from Dave at Megapoints http://t.ly/qZXN as is the button, but all the electronics are MERG.

Support the Channel, become a Patreon Member   / rowantown

Chapters
0:00 Original Panel
2:30 Megapoints Panel and enclosure arrived
6:17 Mounting the buttons to the panel
7:17 Building the panel
8:25 Old panels guts
9:03 Checking the LEDs
10:56 Working on the new panel.
13:12 First power on.
15:15 Rats nest of wires
16:03 Power on with new High Power LEDs
20:15 Bracket to mount panel at an angle
20:59 Panel in place and powering up.
