3D Print Your Own PCB

Here is my process for creating 3D printed 'PCB' style boards. Using Kicad to draw the design, Fusion 360 to create the model, and Bambu Studio to slice it. Simple designs can be made quickly and easily.

Thanks for watching!

3D printer model - Bambu P1S 0.4mm nozzle.
2in copper tape from amazon

Copper foil bridge design referenced from Dave Kni's thread here -https://highvoltageforum.net/index.ph...
"Simple H-Bridge construction with low parasitic inductances"
