Detailed Guide for the AutoCAD Sheet Set Manager
Автор: Elephant Engineering AutoCAD Solutions
Загружено: 2022-07-25
Просмотров: 12801
Please visit the Elephant Engineering website at: https://www.elephant-eng.com/cad-blocks
Step by Step example showing you how to create a new Sheet Set and how to work with the Sheet Set Manager (SSM).
I show you how to:
-Set up your standard border to work with the SSM.
-Rename and renumber sheets using the SSM.
Add sheets to the SSM.
-Organize sheets within the SSM.
-Create automatic sheet references using sheet set fields.
-Print your entire plan set from the SSM with a few clicks.
Time stamps:
0:00 Why use the Sheet Set Manager?
0:45 Set up your border for the Sheet Set Manager.
6:38 Adding sheets to your project.
9:00 Creating the Sheet Set.
11:39 Changing Sheet Set Names and Numbers.
13:35 Adding Sheets to the Sheet Set.
15:44 Organizing the Sheet Set.
16:38 Sheet References using the Sheet Set Manager.
18:47 Printing from the Sheet Set Manager.
