Rod Packing Assembly of a Reciprocating Gas Compressor
Автор: chaitanya kumar
Загружено: 2021-03-29
Просмотров: 6227
Hello everyone,
Today you will see the assembly of PCA(Packing Cup Assembly)
This is a High Pressure side Rod Packing Assembly of Kirloskar Pneumatic 1200SCMH Gas Compressor.
Compressor Model No: CFA32
Motor Rating: 160Kw/215HP
Flow Rate: 1200SCMH
Output Pressure: 240bar
Rod Packing Assembly:
This prevents the gas from compression area from entering the crankcase.
It's consists of 5cups, the No of Cups depends on the types of the rings.
The Rings primarily used are Pressure Ring P-RING), BTR Ring(Backup Ring), B/D Ring, Oil Scrapper or RTV Ring.
Each Cups hold the rings in the following order from 1st Cup to 5th Cup
1. P-Ring
2. BTR Ring
3. BTR Ring
4. BTR Ring
5. BTR Ring
6. Oil Scrapper.
The cup is assembled on 3 studs shown in the video.
Feel free to comment if you have any doubt.
Thank you for watching the video.
