Solid Edge 2023 Tutorial - Practice for Beginners # 5 - Mercedes-Benz Logo
Автор: The Design Engineer
Загружено: 2022-12-24
Просмотров: 5367
This video is one of the exercises for practicing Solid Edge in developing 3D objects (Mercedes-Benz Logo). The video strengthens the use of developing drawing planes and drawing relationships. The video covers the new edition of Solid Edge 2023. The video will teach you some of the basics of 3D solid modeling. Besides the general drawing commands, the video explains how to efficiently use solid edge with particular concentration on Chamfer Equal Setback and Sweep controls. If you are new to Solid Edge, I recommend watching the introduction videos: Introduction to Solid Edge - Part A & Part B - ( • Introduction to Solid Edge - Part A ) & ( • Introduction to Solid Edge - Part B ), as well as the first ten labs of the Solid Edge Tutorial. If you are interested in getting a copy of the PDF dimensions of this video, please use the following link: https://drive.google.com/drive/folder...
Timecodes
00:00 – Intro
02:13– How to start the drawing
04:40 – Drawing the central part
11:23 – Applying the “chamfer equal setbacks” command
12:50 – Creating the rim using the “sweep” command
18:10 – Concluded remarks
