Capacitors are DEAD. Long Live DIODES! ♠ [ How To QUAD ]

Capacitors are dead have you heard? The new Hype is TVS ZENNER DIODES! In this episode I will give you a layman's breakdown of the TVS diode and it's uses and WHY it is superior to the capacitors we have been using on our builds.

Basically, the Diodes provide a safe shunt for transient voltage spikes and ACTUALLY does the job your capacitor should be doing.

The benefits of this technique are a cleaner Gyro and Video as well as added protection to sensitive equipment such as VTX / FC / Camera.

Make sure to subscribe because I will be covering the technique in detail on my next build the Strictly Racing Drones 5" and the 3" Saturn Titan XS.

!!! DISCLAIMER !!!
I have not yet installed this on my quad, I just wanted to share the news and let you know that on my next build I will be using the technique and covering it in detail.

If you want to try this yourself, you do so at your own risk. Make sure to pay attention to the instructions on the video and to mount the Diodes in reverse polarity. Otherwise you will cause a fire.


SCIENCE ( Recommended Reading )
-----------------------------------
What is TVS and How Does It Work? - http://bit.ly/2qWNIuc
Transient Supressive Devices and Principles - http://bit.ly/2qOFIz9
Transient Voltage Supression - http://bit.ly/2psFg4y

GET TVS ZENNER DIODES
-----------------------------------
DigiKey Selection - http://bit.ly/2q3lrTl
Ones Used On Video - http://bit.ly/2pwot1F
4S limited Diodes (+Koen NAir suggested) - http://bit.ly/2pA1r9S

You can buy any of the diodes found on that link, they all should work. Just select the form factor you are most comfortable working with. The SMD ones are fairly large and pretty much span the gap of a ESC quite nicely.
