3DMakerPro EAGLE LIDAR Scanner Review

LIDAR Scanning is measuring millions of dots with LASER and creating 3D landscapes with 2cm accuracy. Additional use of cameras can help colorize these scans to make them look even better. Find out if this is something for you!
"Gaussian splatting" takes it to another level and create even more impressive landscapes!
Learned all of this while researching for my review - covered a lot of topics - so the limits of a youtube description box were reached swiftley ;)
Therefore I created a structured article here: ✅ https://rcschim.blogspot.com/2025/01/...

Update 6/2025:    • 3DMakerPro Eagle LIDAR scanner - see the i...
(most of the complex workflow steps mentioned here have been adressed - now it's really easy to use - even the creation of a gaussian splat is just one click - and a lot of needed CPU/GPU power!)


My Philosophy: Honest, "almost scientific" testing, I test products rigorously and share honest opinions—even if it costs me affiliate earnings. Using my affiliate links supports my work at no extra cost to you! Huge thanks!🙏
🛒International store: https://shrsl.com/4uaeg (Discount code: RCSEG80) get 80$/€ OFF if using my code!
EU/UK store: https://tidd.ly/4b5HIXe (Discount code: RCSEG80)

🌐▬▬▬▬LINKS▬▬▬▬▬▬▬▬▬▬▬▬▬▬🌐
please check my PATREON: https://bit.ly/2ESMtIO 🙏
Manual: https://forum.jimumeta.com/home/help/...
Software download: https://forum.jimumeta.com/home/help/... (RayStudio)


New early march Firmware:
   • eagle update
https://exmail.qq.com/cgi-bin/ftnExs_...

Calibrate files: https://exmail.qq.com/cgi-bin/ftnExs_...

3DMakerPro Facebook Group   / 920361733495397
JimuMeta (3DMaker): https://scene.jimumeta.com
https://gauss.jimumeta.com Demo scene Lake
(online platform starts March 2025)
✅ ALL of my POINTCLOUD example data for you to download and inspect (get free CloudCompare to open it) https://drive.google.com/drive/folder...
💡https://cloudcompare.org (open source! - best pointcloud tool I found during research)
Download Unreal Engine🔥: https://www.unrealengine.com/en-US/do...
Unreal Engine Pointcloud plugin: https://dev.epicgames.com/documentati...

►Product REVIEWS: http://goo.gl/mZkwHr
►TOP Videos: http://goo.gl/MHfr1D
►Mountain DIVES: http://goo.gl/FfXPHa

📋▬▬▬▬FACTS, Specs, TIPS▬▬▬▬▬📋
SMA connector on top (antenna, GPS?)
Lidar Dome in front
Accuracy 2cm for 10 meters, 3cm for 20 meters, 5cm for 40 meters
Scan radius 40-70 meters (more 10% reflectivity or less 80% reflectivity)
Scan range 10-140 meters
Scan angle Horizontal 360°, Vertical 59°
Point cloud frequency 200,000 points/second
Laser light source 905 nm
Eye safety level Class 1 (IEC60825-1:2014) Eye Safety
Color texture 48MP 4-camera system, 360° x 300° support 16K panoramic
photo output
4x 48MP cams (180°, F2.0) but pics seem to be 12mp (4000x3000 super wideagle) (Front, 120° left and right, top)
HDR mode Support (3-5 exposure values)
USB C interface x 2
Data: here you PLUGIN your USBc NTFS stick - not a cable to your PC!
Power: for charging or power during use
Built-in battery 12000 mah, supports 1 hour of work, supports external
Network support Wi-Fi 5
Screen size 3.5”
Output format 3D Color Point Cloud PLY
3D Gaussian Splatting PLY
3D Colored Polygonal Model OBJ
3D Panoramic Tour Data (OBJ)
Volume 115mm x 181mm x 107mm
Weight 1.5 kg
Configuration 8 Cores 2.4GHz 32GB
MicroSD Card slot on bottom (card must be NTFS!)
Battery indicator

🎥▬▬▬EQUIPMENT▬▬▬▬▬▬▬▬▬▬▬▬🎥
my Hangar: http://goo.gl/QNzck
Filmed with: Sony A7c, DJI Mic2, Oneplus 12, edited with Premiere Pro

🙏▬▬SUBSRIBE!!! → http://goo.gl/szFJv ▬▬ 🙏
(¯`·.¸¸.·´¯`·.¸¸.-RCSchim-.¸¸.·´¯`·.¸¸.·´¯)
►   / rcschim
► https://rcschim.BLOGspot.com
► RCSchim@gmx.at
►   / rcschim
►   / rcschim

🔖▬▬▬VIDEO INDEX▬▬▬▬▬▬▬▬▬▬▬🔖
00:00 Intro
01:25 Unboxing
02:42 SPECS
03:50 What's LIDAR?
04:50 Screen UI
05:44 Scanning
08:15 LIDAR vs. Photogrammetry
10:22 gaussian splatting
12:20 COLORED pointcloud
13:33 Lidar Software explained
●▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬▬●
