Direct ink to PCB CNC-Plotter pt. 2
Автор: Dirk Herrendoerfer
Загружено: 2013-12-23
Просмотров: 272233
This is part two of the CNC-Plotter videos for
part one see here:
• Direct ink to PCB CNC Plotter
Part three see here:
• Direct ink to PCB CNC-Plotter pt. 3
This part shows the workflow of a PCB plotting from
start to finish, with added detail to the workings of
the plotter itself.
Remember, the plotter is entirely made of leftover
junk and some brass and CFK material I had lying
around, It is not meant to be fancy or accurate.
As a note to using permanent ink pens with PCB
material: The cleaner the PCB is - the better your
results are, you really need to get the copper to its
best shine, or the ink will come off when etching.
The aduino firmware used for this is available for
download via github. See here:
https://github.com/dherrendoerfer/uCN...
It is published under GPLv2 and should be considered
beta quality.
If you like what you see, and want to help out making this sort of development and production possible in the future, please consider a small donation at:
https://www.paypal.me/dherrendoerfer
This helps a lot in keeping the channel and its content free and un-influenced.
