Opticut Beam saw 2.8 Unbelievable saw carrier speed and optimum thickness cutting

For Details Call: +91-9814006526,+91-9914729333
Moonlit Industries (Regd.)
Railway Road,Opp. Puri Hospital,Sirhind (Fatehgarh Sahib)-140406
India

Follow us:
Facebook:   / princewoodworking
Instagram:   / prince_woodworking_machinery
Website: https://www.modularkitchenmachines.in...
https://www.modularmachines.online
https://www.moonlitind.com

Constant high performance in industrial continues production.Stability and service life of the machine is incredible.

Model No :
OptiCut 2.8
OptiCut 3.2


Salient Features :-
Robust, balanced structure ensuring maximum stability. Specially designed technologies to guarantee precision & rigidity.
Constant high performance in industrial continues production.
Easy accessible, user friendly Smart Touch HD Screen with cutting optimized software programed, is simple to use & gives precision operation with maximum productivity & reduce wastage of material.
Steel ball air floating table, avoiding scratches on board and assuring smooth board movement.
Side aligner, integrated with the saw carriage, can perfectly align given thin or flexible panel, reducing cycle cutting time.
Saw carriage speed can be adjusted from 0-100 m/min Maximum cutting thickness up to 100 mm.
All electronic & pneumatic parts are from well-known international brands.
Ensuring longer machine life, safe operation, reduced unscheduled downtime and more economical operation costs. Low maintenance m/c, easy available cost effective spares, best service support.

Model/Unit
OptiCut 2.8
OptiCut 3.2
Max. cutting length
mm
2800
3200
Max. cutting thickness
mm
100
100
Saw carriage forward speed
m / min
100
100
Saw carriage backward speed
m / min
150
150
Main saw blade size
mm
400Φ x 60Φ
400Φ x 60Φ
Speed of main saw blade
rpm
4000
4000
Main saw motor
hp
21.2
21.2
Scoring saw blade size
mm
180Φ x 30Φ
180Φ x 30Φ
Speed of scoring saw blade
rpm
6500
6500
Auto feeding motor (AC servo)
hp
1.3
1.3
Feeding speed
m / min
100
100
Saw carriage drive motor
hp
3.0
3.0
High pressure blower motor
hp
4.0
4.0
Working air pressure
Kg / cm²
5~7
5~7
Total power
hp
29.5
29.5
