ShaftAlign Touch | How to Enter Dimensions for Shaft Alignment Setup
Автор: PRUFTECHNIK Group
Загружено: 2023-11-10
Просмотров: 1605
Learn how to set up a measurement by entering dimensions on the Pruftechnik ShaftAlign Touch, from Fluke Reliability.
In this tutorial, you’ll see step by step how to:
Mount the laser sensor unit and prism correctly
Enter key dimensions including sensor-to-prism distance, center of power transfer, and foot bolt spacing
Measure coupling diameter and calculate diameter from circumference
Input RPM for accurate tolerance settings
Prepare your ShaftAlign Touch for precise alignment measurements
Correctly entering dimensions ensures accurate alignment results, reduces errors, and improves machine reliability. With ShaftAlign Touch, even setup becomes straightforward and efficient.
For more information about ShaftAlign Touch, visit ► https://www.pruftechnik.com/products-...
