Building Basic Ladder in Automation Studio with Relays
Автор: Lars Explains
Загружено: 2022-10-19
Просмотров: 6176
Описание:
Drawing a basic ladder logic circuit with Automation Studio.
The circuit contains memory latches and the basic counter which allows a single push button to turn on a lamp and when pressed a second time we'll turn off the lamp.
This is a good example of ladder logic programming that has a single event, such as a push button being pressed, that does a different thing to the circuit the second time it is pressed.
