Design of the Current Controller for DC-DC Converters in Continuous-Time Domain (1/5)

I have prepared a series of follwing five videos explaining ''Cascaded Control Design for DC-DC Converters.'' Further, the equations to tune the PI controller gains for both inner current and outer voltage control loops are derived. The proposed control loops habe been analyzed and validated using a Matlab/Simulink simulation environment.

These lectures will help you build a strong foundation for designing any controls in continuous-time and discrete-time domains. If you find power converters and controls exciting then I would suggest you watch these videos. Feel free to like, share, comment, and subscribe to the channel.

The learning objectives:
1. Understanding the basics to design converter controls in continuous-time and discrete-time domains
2. Direct discrete-time and continuous-time plant models derivation
2. Derivation of the PI tuning expressions
3. Cascade control implementation of outer voltage and inner current control loops
4. Protection of converter during overload and faulty conditions
5. Importance of implementation of anti-winding for the integrators

Lesson-1: Design of the Current Controller for DC-DC Converters in Continuous-Time Domain (   • Design of the Current Controller for DC-DC...  )
Lesson-2: Design of the Current Controller for DC-DC Converters in Discrete-Time Domain (   • Design of the Current Controller for DC-DC...  )
Lesson-3: Design of Outer Voltage Controller for DC-DC Converters in Continuous and Discrete-Time domains (   • Design of Outer Voltage Controller for DC-...  )
Lesson-4: Implementation and Validation of the Proposed Inner Current Control Loops using MATLAB/SIMULINK (   • Implementation and Validation of the Propo...  )
Lesson-5: Implementation and Validation of the Proposed Outer Voltage Control Loops in MATLAB/SIMULINK (   • Implementation and Validation of the Propo...  )

Hand Written Notes:
https://drive.google.com/file/d/13QFW...

Link to Download Inner Current Controller (ICC) Simulink Model: https://drive.google.com/file/d/1aqPA...

Link to Download Outer Voltage Controller (OVC) Simulink Model: https://drive.google.com/file/d/1PBBd...
