how to make high pass filter । high pass filter circuit । 4558 ic । high pass filter for tweeter

how to make high pass filter । high pass filter circuit । 4558 ic । high pass filter for tweeter

Hi
I am ARNAB GIRI. Welcome to Our YouTube Channel Tech Warm Touch.


Component-
4558 ic - 1
3k- 1
72k-1
390k-1
560k-1
472j (.0047mfd)-3

About this video:-
A simple RC Passive Filter connected to the non-inverting terminal of an operational amplifier is shown below. This RC circuit will provide a low frequency path to the input of the amplifier. The amplifier acts as a buffer circuit providing unity gain output. This circuit has more input impedance value. I hope you like this video. Thank you so much.


WARNING:-
This video is intended solely for demonstration and educational purposes.
Each demonstration within this video entails inherent risks and hazards that must be comprehensively understood before any attempts are made.
It is imperative that only trained professionals undertake these demonstrations. The content showcased in this video is not suitable for inexperienced individuals,
and attempting to replicate the activities without adequate knowledge and expertise could result in severe injury or harm.
Prioritize safety at all times and exercise extreme caution when engaging in any similar activities.
