DIY Drill Disc Sander | Drill Powered Disc Sander

I made a drill-powered disc sander.

► For more details check out my website: https://allflavorworkshop.com/
► Tutorial and Plans available: https://allflavorworkshop.com/drill-p...
► ALL Woodworking Plans: https://allflavorworkshop.com/woodwor...

I've been wanting to make a disc sander for some time. I finally got to make one. It is a 20 cm drill-powered disc sander. The great thing is that all of the parts are detachable - the drill platform, the support of the disc sander, and the table. As for the drill platform I got to reuse the drill press stand I built earlier. The other parts can be easily reused for other workshop jigs. The removability of the individual parts also reduces vibrations and wobbling of the machine. There is hardly any wobble at all. Also sanding discs can be easily removed and it is possible to replace the disc with a disc of a different size. The disc sander can be easily clamped to a workbench.

Tips:
Use a circle cutting jig to make a perfect circle for the disc sander
Use epoxy steel bond (long cure) to bond the shaft with the sanding disc
File shapes into the rod for better fixation
Use liquid spray adhesive for temporary sandpaper fixation. The sandpaper can be easily removed a replaced with a new one.

🛠 Tools and Material (affiliate links):
Trim Router – https://amzn.to/3HbQcOg
Corded Hand Drill (Drill Stand) – https://amzn.to/3NSA3Bo
Angle Grinder – https://amzn.to/48K2klD
Table Saw – https://amzn.to/47mWiGf
Cordless Hand Drill – https://amzn.to/3HqLEnH
One Hand Clamps – https://amzn.to/48jGxkZ
Spring Clamps – https://amzn.to/41Nuh9D
F-Clamps – https://amzn.to/48ArzY1
Machinist Square - https://amzn.to/48fT6xw
Speed Square - https://amzn.to/3RO67Hy
Center Hole Punch – https://amzn.to/48Fq7mv
Wood Glue – https://amzn.to/48ltKhJ
Epoxy for Metal – https://amzn.to/3vAv1ms
Liquid Spray Adhesive – https://amzn.to/48GuvBP
Forstner bits – https://amzn.to/3Hd1aDb
Straight router bit – https://amzn.to/3tLCSNO
Sandpaper Sheets – https://amzn.to/41OMx2p
Bearings – https://amzn.to/3voT2gl
M6 Bolts, Washers, T-nuts, Screws – https://amzn.to/41PodgQ
Steel rod – 6mm – https://amzn.to/3tA8g1L
Plywood 12mm – https://amzn.to/3TPULp2
Plywood 9mm

🛠 All My Tools & Gear:
https://allflavorworkshop.com/tools-a...

We may earn an affiliate commission when you buy something through our retail links. As an Amazon Associate AllFlavor Workshop earns from qualifying purchases.

► Subscribe To AllFlavor Workshop YT Channel: https://bit.ly/2T9cIxD
► Sign up for my newsletter: https://allflavorworkshop.com/mailing...

► Other helpful tutorials:
   • Make a Drill Press Stand | Drill Press Sta...
   • Router Circle Cutting Jig | DIY Router Cir...
   • DIY Angle Grinder Stand | Benchtop Angle G...

► Follow me on:
Website - https://allflavorworkshop.com/
Pinterest -   / allflavorworkshop
Instagram -   / allflavorworkshop

If you have any thoughts or questions, let me know in the comments below and I will get back to you as soon as possible. I am not a professional but I like making something new with my hands. Any suggestion or advice is highly appreciated.

TIMESTAMPS:
00:00 Drill Disc Sander Demonstration
00:45 Making the sanding disc
02:10 Cutting a steel rod
03:41 Making supports for the disc sander
04:33 Inserting bearings
07:54 Fixing the Stand to the base
09:18 Making the drill platform
12:02 Building a table for the sander
14:03 Testing Drill Disc Sander

Thank you all for watching and for your support.
#discsander #drillsander #sander #smallworkshop #woodworking #allflavorworkshop
----------------------------------------------------------------------
WARNING:
All information, processes, and working procedures provided by AllFlavor Workshop are of a general nature and are furnished only for educational/entertainment purposes only. No information is to be taken as professional advice. You agree that the use of this information is at your own risk and hold AllFlavor Workshop harmless from any and all losses, liabilities, injuries, or damages resulting from any and all claims.

HAVE FUN BUT ALWAYS KEEP SAFE!
----------------------------------------------------------------------
