How To Assemble the Lat/Low Row for 4000 & 5000 Series Racks | Step-By-Step Instructions

Congratulations! You just purchased one of the most versatile pieces of equipment for your home gym: The REP Lat/Low Row Attachment. Follow these step-by-step instructions to install the attachment with ease:

How to Install the REP Lat/Low Row (4000 & 5000 Series Racks)
Step 1) Install Rear Base Stabilizer (RBS) on rack (2:16)
Step 2) Attach front base of Lat Low Row to RBS (2:47)
Step 3) Attach guide rods to rear base of lat low row & Tighten bolts (3:34)
Step 4) Attach rear base to front base (4:53)
Step 5a) Slide on rubber donuts, then trolley (no weight horns) (5:25)
Step 5b) Attach weight horns to trolley and tighten bolts (6:18)
Step 6) Attach upper pulley beam onto both Logo plate and guide rods (7:20)
Step 7a) Route upper cable (goes above bar on upper pulley bar, not inside) (9:18)
Step 7b) Install pulleys for upper cable (10:03)
Step 8a) Route lower cable (13:49)
Step 8b) Install pulleys for lower cable (14:29)
Step 8c) Adjust lower cable tension with chain (15:39)
Step 9) Insert foot pad and install spring pin/knob (17:01)
Step 10) Tighten all hardware (bottom to top)Ensure top and bottom squareness (17:58)
Step 11) Silicone spray on guide rods (18:21)

If you have any questions throughout the installation process, email us at orders@repfitness.com and our awesome customer service team will help you out!
