Assembling Bilstein PSS10 B16 - MK7 GTI
Автор: Doctor Navi
Загружено: 2020-03-20
Просмотров: 1029
Assembling the front Bilstein PSS10 B16 coil over for an MK7 GTI. (rear assembly is self explanatory). Proper tools, torque specs and technique used.
No impact or air tools used.
Torque spec for top strut bolt on the Bilstein PSS10 B16 is 72 Nm/54 ft/lbs. This is based on the measurement of the thread which is M14. For the rear Bilstein PSS10 coilover stut, the torque spec is 25Nm/19 ft/lbs. based on Bilstein install manual torque specs for an M10 thread. If your threads are different size on other Bilstein models then these torque specs are NOT correct for you.
OEM BOLT SPECS
Front Suspension
Pinch bolt N90954802 x2 - 70Nm +90
Pinch nut N10106402 x2
Strut mount bolts N10127707 x6 - 15Nm +90
Control arm bolts N10640501 x4 - 70Nm +180
Control arm to ball joint on hub nuts N10332002 x6 - 40Nm +45
Rear Suspension
Strut to control arm bolt N10628301 x2 - 70Nm +180
Strut to control arm nut N10106402 x2
Hub to control arm bolt N10640501 x2 - 70Nm +180
Hub to control arm nut N10106402 x2
Sway bar to control arm bolt N10776501 x2 20Nm +180
Sway bar to control arm nut N90183803 x2
Sway bar bracket to chassis 20Nm +90
Strut mount to chassis N90648402 x4 - 50Nm +45
