Joe shows you how to install an Extended Roof Bracket.

An Extended Roof Bracket is needed to support any Class A chimney pipe when it extends more than 5' above the roof, or just for that added stability in high wind or snow areas. It provides needed stability for the chimney against wind and snow. Legs extend from 62 Inches to 114 Inches. Mounting brackets and adjustable tubing is included. You will need to provide your own screws to attach the roof support to the roof, all other screws are included.

First attach the bracket that goes around the pipe by placing it just above any seam and gently secure with the screws provided, do not tighten until the end to make sure placement is correct. The side brackets are adjustable to allow proper placement of the legs. Next you will need to assemble the legs to get ready for installation.

To attach the legs you will need to use 2 of the shorter bolts and attach to the bracket, lightly tighten. You will want an approximately 60 degree angles from the pipe to ensure proper support. Attach the roof brackets to the roof in the desired placement, this is where you will need to provide your own screws. Screw down the bracket and be sure to seal with a waterproof sealant to prevent and leaking.

Next you will need to secure the legs with the included long screws in the position you want, You will insert the bolt through the provided holes in the legs and tighten.

Ensure proper position and tighten all bolts. Check for any other issues that may have come up such as a gap in the seal around the storm collar due to the movement of the chimney pipe.
