24" Viewlix Vertical Bartop build from Game Room Solutions PART 3!!! ALL FINISHED!

In this video I finish the build on my new 24" Vertical Viewlix Bartop from GRS, this is part 3 and I will show the entire process from start to finish in this video series!

SNC Play Fore Her Women’s Golf Outing
https://www.snc.edu/alumni/event/play...
(This machine will be donated as a raffle item at the event)

Game Room Solutions build guide for this cabinet:
   • Table Top Viewlix Vertical Arcade Cabinet

Game Room Solutions Product Link:
https://gameroomsolutions.com/shop/24...
(not sponsored)

Addressable 5v LED round white PCB sheet (100 LEDs):
https://www.amazon.com/ALITOVE-100pcs...

LED wire I switched to (the smaller gauge) use just 3 of the conductors:
https://www.amazon.com/EvZ-22AWG-Elec...

Sample button type I used, note these say 12v but that's only if you use the included LEDs and LED holders...
https://www.amazon.com/EG-STARTS-Arca...



----------------------------------------------------------------------------------

My Arcade Cabinet Build:

Cabinet:
RecRoomMasters 32" Pro Upright Xtension Arcade Machine "Emulator Edition Plus" - https://www.recroommasters.com/32-Pro...

PC:
Motherboard: ASRock B250M-HDV
CPU: Intel Core i5-7600K
CPU Fan: Cooler Master Hyper 212
GPU: EVGA GTX 1070 SC GAMING
Memory: G.Skill 16GB 2x8GB
Storage: 500GB Samsung 850 EVO SATA 6Gb/s SSD, 4x 8TB 5400rpm WD 3.5" Drives
PS: Corsair CX850
Open frame Bench Case

TVs:
Main Display: Samsung 32" 1080p 7 series
Marquee: 34" Vitrolight 1920x340 Custom LCD

Control Panel:
Xtension Control Board "Emulator Edition Plus" (modded)
I-PAC mini with the Ultimarc PAC-LED64 for LED button/joystick control
Ultimarc GoldLeaf RGB Illuminated Buttons
Ultimarc U-Trak FlushMount Arcade Trackball with Transclucent ball and RGB LEDs
2x Ultimarc J-Stik RGB LED Ball-Top Joysticks with custom 3D printed octagonal gates

Lightguns:
2x AimTrak Light Gun With Recoil
2x Custom Light gun holsters mounted behind main display
600watt 36v Switching PSU
Mayflash Dlophin Bar for WiiMote support

Audio:
Logitech 2.1 Z333 Speakers

Misc:
Power management: TrickleStar 7 Outlet Advanced powerstrip to turn on displays when PC is powered on
Real Coin door with modded 7-Port USB hub with selectable inputs (used for lightbar selection and gamepads)
Sound reactive RGB LED cabinet lighting
Launchbox / BigBox front end with LEDBlinky support
