1983 Honda GL1100 Goldwing Head Gasket Replacement
Автор: Mr Mark G
Загружено: 2022-07-08
Просмотров: 13278
Here are the steps that I took to replace the head gaskets on my 1983 GL1100I Goldwing. This video will also apply to many other early Goldwings. Parts used listed below.
Qty Part Number Description
2 - 91209-371-003 OIL SEAL (27X43X9) - OIL SEAL (27X43X9)
1 - 91209-463-013 SEAL, CAP (43X9) - SEAL, CAP (43X9)
4 - 90452-323-000 WASHER, SEALING (5MM) - WASHER, SEALING (5MM)
1 - 91206-286-013 OIL SEAL (14X28X7) (ARAI) - OIL SEAL (14X28X7) (ARAI)
1 - 91256-425-003 OIL SEAL (4.8X14.5X5) (ARAI) - OIL SEAL (4.8X14.5X5) (ARAI)
1 - 90016-415-000 BOLT, SPECIAL (6X45.5) - BOLT, SPECIAL (6X45.5)
1 - 12361-300-000 CAP, VALVE ADJ. - CAP, VALVE ADJ.
1 - 90325-044-000 NUT, TOOL BOX SETTING - NUT, TOOL BOX SETTING
2 - 91308-371-003 O-RING (4.1X1.5) - O-RING (4.1X1.5)
1 - VG-195 Vesrah Complete 1983 GL1100I Gasket Kit
1 - VG-595 Vesrah Top End Gasket Kit - GL1100
