FDOTSS4 Urban Driveway Modeling

Date: 10/7/15
Presenter: Vern Danforth, CADD Support Engineer

In this webinar, we will discuss two methods for modeling driveways for an urban design project and the advantages or disadvantages of each. The methods include 3D Civil Cell and Driveway Template Components.

Presentation:
http://www.dot.state.fl.us/ecso/downl...

Question & Answers:
http://www.dot.state.fl.us/ecso/downl...

Support Files:
http://www.dot.state.fl.us/ecso/downl...

Table of Contents:

00:00 - Introduction
02:11 - Driveway Template Component Steps
04:45 - 3D Urban Driveway Civil Cell Steps
07:56 - Advantages & Disadvantages of Each Method
08:00 - Driveway Template Components
08:26 - 3D Urban Driveway Civil Cell
08:57 - Advantages & Disadvantages Summary
09:51 - Driveway Template Components (Live)
10:02 - Place Reference Line
10:26 - Place 2D Urban Driveway Civil Cell
11:19 - Note: Driveway Modifications
12:27 - Note: Civil Cell Improvements
14:03 - Copy Driveway - Modeling Template
15:18 - Add Drop Curb Driveway Template
22:24 - Set Curb Parent-Child Relationship
24:28 - End Conditions
27:02 - Change Project Design Stage Settings
29:20 - Add Corridor References
30:30 - Synchronize Template Drops
33:47 - Gaps
34:33 - Add Profile to BSW Lines
35:28 - Re-Apply Superelevation Point Control
36:12 - 3D Urban Driveway Civil Cell
36:16 - Place Reference Line
36:54 - Add Profile to EOP and BSW Lines
40:03 - Note: Profile By 3D Element Tool
41:10 - Place 3D Urban Driveway Civil Cell
43:30 - Modify Main Curb Back Top Width (Tolerance for Clipping)
45:05 - Corridor Clipping
46:43 - Issue: Type F Curb Not Clipping
48:09 - Question: Can You Skew a Driveway on a Curb?
48:34 - Question: Change Template for Every Civil Cell Placed or can They be Copied?
50:12 - Summary Review
50:20 - Driveway Template Component
51:41 - 3D Urban Driveway Civil Cell
53:37 - Question: What if I don't want the Civil Cell Tie Down?
