Powder Grinding Mill: MTW European Trapezium Mill

MTW Trapezium Mill
Large capacity, Low consumption, Environmental friendly

MTW European Trapezium Mill has a large market share in the grinding industry. Whether bevel gear overall drive, inner automatic thin-oil lubricating system or arc air channel, these proprietary technologies makes machine advanced, humanized and green.

Applications: Cement, coal , power plant desulfurization, metallurgy, chemical industry, non-metallic mineral, construction material, ceramics.

Input Size: 33-40 mm

Processed Materials:
Limestone, calcite, barite, dolomite, potassium feldspar, bentonite, medical stone, rock phosphate, manganese ore, iron ore, quartz, active carbon, carbon black, ceramic, coal, ect.

More information:
1. Efficient
Bevel gear overall drive reduces noise and increases drive efficiency and capacity.Inner automatic thin-oil lubricating system makes better lubrication for bearings
2. Economical
Edge-replaceable shovel saves you money and frequency-control separator and cyclone powder collector ensure high capacity
3. Advanced
Arc air channel reduces energy consumption and intelligent control ensures better operation
4. Environmentally friendly
Unique air recycling system and dust collector make clean environment

Working Principle
The system consists of grinding mill, separator, air blower, jaw crusher, vibrating feeder, hopper, dust collector, pipe, powder collector, electric cabinet, motors, etc.

Big lump materials are crushed to required size by jaw crusher, then elevated to buffering hopper through elevator, after that fed into the mill to be ground. Materials are to be ground between ring and rollers, and move up with the air flow, those particles which cannot pass the separator will fall down and be ground again, while others will be collected as finished product. Air flow passing through separator will go to the air blower for recycling, it's a closed system.

Maintenance tips
1.The main machine should run smoothly without abnormal noise. The temperature of the bearing chamber should not exceed 50℃.
2.After 30 minutes of testing, stop the machine and tighten the bolts in turn again. Then we can use it.
3.After normal operation, check once a week to avoid loosening bolts.
