M35A2 and other Military Vehicle Air Governor Adjustment

M35A2 (and other Military Vehicle) Air Governor Adjustment

Hello and best wishes!
My 1968 truck has the old style air governor.
If you have an old truck there is a chance you have this one also.
Note there are likely many different air governors that were used, but I think most 1950 and newer military trucks have the old or new style mentioned here.
My truck would maintain pressure at about 80 psi and I was curious if bumping it up a bit would help with braking.
So, I turned it up to just over 100psi per the old style governor instructions.
I also found that adjusting it any lower than 80psi (just a tad from where mine was when I got it) made it short cycle and generally act up, so I think t was set right at the lowest pressure without misbehaving.
I'll give it a spin soon (after I adjust the brakes as I do it every Summer) and see how it behaves.
Please refer to the proper tech manual for reference!
TM for Old style governor:
TM9-2320-209-20-3-2 Organizational Maintenance Multifuel 2
TM for New style governor:
TM9-2320-361-20 Unit Maintenance newer
If you are interested in the pressure gage I used:
McMaster-Carr p/n 4000K727, 3 ½ dial, ¼ M NPT rear center fitting, 0-160psi (about $13)
