How to fix Android 11 No AUX Sound Issue 12.5" Screen C63 W204 W205 Mercedes Benz 2022 Part 1
Автор: KevinKitHo
Загружено: 2021-12-12
Просмотров: 30708
#mercedes #w204 #customexhausts #mercedesbenz #benz #amg
Quick overview of how I fixed the no sound issue after installing the new Android entertainment unit/display.
Usually the “audio In” Jack is connected via a 3.5mm aux cable which is then ran down into your glove box or centre console where it’s plugged in. (For me this was into my AMI/MMI slot using the adaptor supplied with the kit)
In the end I gave up on this method and instead a much simpler method I found was to just plug the 3.5mm aux cable coming from “audio in” into the other “audio out” Jack rather than into the centre console AUX. This can be found with the bundled cables going into the display unit itself with a bunch of other cables labelled DVR, AV in, AV out etc…
Once this was done I then modified the settings under the Mercedes engineering menu
(hold red Hangup button+1+#) OR either of the town below if the above does not work.
(Hold red hangup button+2+#)
(Hold green dial button+1+#)
** Do this at your own risk, my video is for information only demonstrating how I achieved this**
Once updated and reset, you can then navigate and finalise additional Android settings.
Took me a few attempts as was not simply plug and play, ordered 2 AMI cables only to send them back, but fortunately turns out they are not needed IF You have the additional “3.5mm Audio Out” Jack.
** I’ve added a photo at the end of the video to show you how I wired it up**
Mercedes C350 coupe w204 2011
NTG:4.5
Hope this helps some of you
