Create a probe model by In-Situ De-embedding (ISD)
Автор: AtaiTec
Загружено: 2021-02-28
Просмотров: 1190
Описание:
Live demo on how to create a probe model using Anritsu vector network analyzer (VNA), DVT Solutions 70GHz differential probe and AtaiTec In-Situ De-embedding (ISD) software.
Questions to ponder:
• What are the advantages of using 1x open + 1x short + in-situ measurements to create a probe model?
• Why don't we use a 2x thru (e.g., placing two probes back to back)?
• Do we need to create a probe model by ourselves or can we just accept a probe model as is from the manufacturer?
See application note at https://ataitec.com/docs/ISD_for_prob...
