Swordfish Tutorial - 01 Hull Orientation + Tips for Grasshopper Beginners
Автор: Swordfish 3d
Загружено: 2021-07-02
Просмотров: 1506
This tutorial shows how to set your Rhino file and work correctly with Swordfish 3D - the new Grasshopper plugin for naval architecture.
You can create a hull from Swordfish or import a geometry from Rhinoceros. You can import single surface hulls, multiple surfaces hull or a polysurface a as a Brep.
Edit your geometry and visualize live results!
Remember the rules:
Only the half starboard
Bow in 0
X-ve afterward
Waterplane = XY Plane (Z = 0)
Set your Rhino file unit in mm!
www.swordfish3d.com
Download: https://www.food4rhino.com/en/app/swo...
Instagram: / swordfish3d
LinkedIn: / swor. .
