Review: Dapol Class 22 Diesel 4D-012-005 D6331 BR Green - Imperium DCC Fitted
Автор: EuviRail
Загружено: 2019-05-23
Просмотров: 2858
Review of the Dapol 4D-012-005 Class 22 Diesel D6331 BR Green with Dapol Imperium DCC Controller fitted.
DCC Controls (based on Imperium controller)
F0 - Light engine mode. Front and rear lights illuminate appropriately in the direction of travel.
F1 - Hauling mode (No.2 end facing train) No.1 end lamps only illuminate (White forwards, red reverse). No.2 end lamps are off.
F2 - Hauling mode (No.1 end facing train) No.2 end lamps only illuminate (white forwards, red reverse). No.1 end lamps are off.
F3 - No.1 end cab light On/Off control. Not directional.
F4 - No.2 end cab light On/Off control. Not directional.
If you are using a Hattons 4-channel decoder and just want your standard directional lighting, configure as follows:
CV49=0
CV50=16
CV51=16
CV52=0
Turn F0, F1 and F2 ON to enable.
You won't have enough channels to control the cab light I'm afraid.
