AnyCAD: Your Key to Revit and Inventor Collaboration

The ability to simplify and share Inventor designs to Revit, making it possible for manufacturers to design their products in Inventor and later simplify and insert them into Revit projects, has been around for a decade. As BIM has evolved, we see more of our customers looking to open Revit models directly into Inventor. Autodesk Inventor’s AnyCAD technology allows you to reference Revit files directly into your Inventor design.

With AnyCAD, you can work with colleagues who are using Revit without translating their files—giving you the confidence that you can create references to geometry knowing that the linked file will update when you receive a new version. Watch as we go from Revit to Inventor and back again with a little help from AnyCAD.

Timestamps
0:00 Introduction
3:35 Steps for Inventor Export to Revit
5:03 Shrinkwrap Tool
16:48 Add MEP Connectors
19:51 Author and Export Building Components
21:37 Inventor Export to Revit Demo
36:06 Steps for Revit Export to Inventor
43:57 Inventor Preparation and AnyCAD
46:55 Revit Export to Inventor Demo
55:13 Q&A
